AmSteel Blue is a torque-free, 12-strand single braid that yields the maximum in strength-to-weight ratio and, size-for-size, is the same strength as steel-yet it floats. AmSteel Blue is an excellent wire rope replacement with extremely low stretch, and superior flex fatigue and wear resistance.
| Diameter Inches | Diameter MM | Average Strength | Weight Lbs/100′ |
|---|---|---|---|
| 7/64″ | 2.5 mm | 1,600 Lbs | 0.30 |
| 1/8″ | 3 mm | 2,500 Lbs | 0.50 |
| 5/32″ | 4 mm | 4,000 Lbs | 0.75 |
| 3/16″ | 5 mm | 5,400 Lbs | 1.00 |
| 1/4″ | 6 mm | 8,600 Lbs | 1.60 |
| 5/16″ | 8 mm | 13,700 Lbs | 2.70 |
| 3/8″ | 9 mm | 19,600 Lbs | 3.40 |
| 7/16″ | 11 mm | 23,900 Lbs | 4.50 |
| 1/2″ | 12 mm | 34,000 Lbs | 5.90 |
| 9/16″ | 14 mm | 40,500 Lbs | 7.90 |
| 5/8″ | 16 mm | 52,800 Lbs | 10.20 |
| 3/4″ | 18 mm | 64,400 Lbs | 13.30 |
| 7/8″ | 22 mm | 90,800 Lbs | 19.60 |
| 1″ | 24 mm | 109,000 Lbs | 21.80 |
